• it is mainly used for electricity metering in residential distribution system
• it can be surface mounted or embedded, and can realize the change of installing electronic meter, mechanical meter and electric card meter.
• in terms of structural design, it is designed according to the principles of standardization, serialization and generalization, which can meet the requirements of safe operation.
• high reliability of operation verification in more than 50 countries and regions around the world
• it is mainly used for electricity metering in various fields such as real estate, housing construction and so on
• the electrical performance fully complies with the relevant provisions of GB7251 and
IEC 60439
Product advantage
> Leading technology
- Standard anti-corrosion and salt spray environmental plan to meet the stringent environmental requirements of the site
- It can be equipped with circuit breakers of various domestic and foreign brands, such as Chint NXBF series, ABB TS200 series, Schneider A9/E9 series, etc
>Electrical Cabinet Features
-the whole is welded with 1.5mm high-quality cold-rolled hot-dip galvanized plate or stainless steelF
- cutting, punching and bending with laser numerical control equipment to ensure machining accuracy
-size and material can be specified and customized
- the cabinet is sprayed with RAL7035 outdoor plastic powder on both sides, and the paint will not come off for 50 years
> Functional units
- The door is equipped with voltage, current indicator meters and signal lights, buttons, transfer switches and other main command components
- New rotary load isolating switch is adopted in the box, which can be operated with load on the front
> Processing and assembly
- Dust-free workshop to ensure insulation
- Assembly workers have been trained for at least 6 months
>Functional unit
-it can realize cable incoming line or overhead incoming line, and can be installed in open hanging or embedded mode; By changing the cover of the meter room, the change of installing electronic meter, mechanical meter and electric card meter can be realized.
- the anti-theft electric structure is set in the box, which can not open the meter junction box even if the lead seal falls off.
Product parameters
>Waterproof grade IP56
Meet iec60529:2001 standard
For detailed parameters, please contact our salesperson
Conditions of use
- Altitude shall not exceed 2000m
- The ambient air temperature shall not be higher than +40 degrees, or less than -5 degrees
- ambient air humidity does not exceed 50%, low temperature allows a large relative temperature (e.g. +20 ° for 90%)
- Electrical components are free from corrosion and conductive dust
Ordering instructions
> The customer shall provide the following information:
- Box drawing
- Main circuit scheme diagram, secondary circuit system diagram and auxiliary circuit control mode
-Brand and model of main electrical components of the equipment
-Other special requirements can be negotiated with hengfengyou electric
Our Advantages
- Authoritative product certification: ISO CE, CB, CCC, etc
- Perfect SQA quality management system to ensure high quality products
- Quick quotation, can provide electrical design services
- The delivery period is short, and the fastest delivery time is 15 days worldwide
- Perfect after-sales service system, so that customers buy worry-free
