Japanese transformer standard(JIS Transformer standards)

Writer： Hengfeng you electric Time：2023-05-09 views：times

Japanese transformer standard, Japanese <a href='https://www.hengfengyou.com/jishu/373.html' target='_blank'><u>JIS</u></a> standard, Japanese transformer <a href='https://www.hengfengyou.com/jishu/373.html' target='_blank'><u>JIS</u></a> standard

Japanese industrial standards (JIS) are the most important and authoritative national standards in Japan. Developed by Japan Industrial Standards Survey (JISC).

The voltage of medium voltage power grid in Japan is 22kv. Low voltage: 100 / 200V (single-phase), 200V (three-phase); Frequency: 50Hz. Hengfengyou electric complies with JIS and Kema CB standards and has provided customized services for oil immersed transformer cores and transformers for many Japanese transformer companies.

编号	中文名称日本語標題	英文名称
JIS C1216-1995	交流电度表(通过仪表用变压器连接) 電力量計（変成器付計器）(廃止)	Alternating-current watt-hour meters (for connection through instrument transformer)
JIS C1216-1-2009	電力量計（変成器付計器）―第１部：一般仕様	Alternating-current watt-hour meters (for connection through instrument transformer) -- Part 1: General measuring instrument
JIS C1216-2-2009	電力量計（変成器付計器）―第２部：取引又は証明用	Alternating-current watt-hour meters (for connection through instrument transformer) -- Part 2: Measuring instruments used in transaction or certification
JIS C1731-1-1998	测试用和与一般仪器一起使用的仪器变压器.第1部分:电流变压器計器用変成器　―　（標準用及び一般計測用）　第１部：変流器	Instrument transformers for testing purpose and used with general instrument Part 1: Current transformers
JIS C1731-2-1998	测试用和与一般仪器一起使用的仪器变压器.第2部分:电压变压器計器用変成器　―　（標準用及び一般計測用）　第２部：計器用変圧器	Instrument transformers for testing purpose and used with general instrument Part 2: Voltage transformers
JIS C1736-2003	计量仪器用仪表变压器計器用変成器（電力需給用）	Instrument transformers for metering service
JIS C3609-2000	架杆变压器用高压绝缘用户设备引入电线高圧引下用絶縁電線	High-voltage drop wires for pole transformer
JIS C4304-2005	6kV油浸式配电变压器配電用6ｋＶ油入変圧器	6 kV Oil-immersed distribution transformers
JIS C4306-2005	6kV密封绕组式配电变压器配電用６kVモールド変圧器	6kV Encapsulated-winding distribution transformers
JIS C5310-1997	电子设备用变压器通用规范電子機器用電源変圧器品目別通則	Generic specification of transformers for electronic equipment
JIS C5311-1994	电子设备用电力变压器的试验方法電子機器用電源変圧器試験方法	Testing methods of power transformers for electronic equipment
JIS C5320-1994	电子设备用高频线圈及中频变压器的通用规则電子機器用高周波コイル及び中間周波変成器通則	General rules of high frequency coils and intermediate frequency transformers for electronic equipment
JIS C5321-1997	电子设备用高频电感器和中频变压器的试验方法電子機器用高周波コイル及び中間周波変成器試験方法	Methods of test for high frequency inductors and intermediate frequency transformers for electronic equipment
JIS C6421-1994	收音机用中频变压器放送受信機用中間周波変成器	Intermediate frequency transformers for broadcast receiver
JIS C6435-1989	低频变压器和电感线圈的测试方法低周波変成器及びコイル試験方法	Testing methods for low frequency transformers and inductors
JIS C6436-1995	电子设备用电力变压器電子機器用小形電源変圧器	Power transformer for electronic equipment
JIS C8105-2-6-2000	灯具.第2部分:安全性特殊要求.第6节:白炽灯用内装变压器或变换器的光源照明器具　―　第２－６部：変圧器内蔵白熱灯器具に関する安全性要求事項	Luminaires -- Part 2: Particular requirements for safety -- Section 6: Luminaires with built-in transformers or converters for filament lamps
JIS C8109-1999	霓虹灯变压器ネオン変圧器	Luminous-tube transformers
JIS C8361-1984	遥控变压器リモコン変圧器	Remote control transformers
JIS C9317-1995	便携式点焊机用焊接变压器ポータブル・スポット溶接機用溶接変圧器	Welding transformers for portable spot welding machines
JIS C9323-1999	电阻焊.变压器.适用于所有变压器的通用规范抵抗溶接機用変圧器　―　全変圧器に適用する一般仕様	Electric resistance welding -- Transformers -- General specifications applicable to all transformers
JIS C9742-2000	绝缘变压器和安全绝缘变压器.要求絶縁変圧器及び安全絶縁変圧器　―　要求事項(廃止)	Isolating transformers and safety isolating transformers -- Requirements
JIS C9742 ERRATUM 1-2001	绝缘变压器和安全绝缘变压器.要求(勘误 1)	Isolating transformers and safety isolating transformers -- Requirements (Erratum 1)
JIS E5007-2005	机动车辆用牵引变压器和电感器鉄道車両－主変圧器及びリアクトル	Traction transformers and inductors for rolling stock
JIS F8066-2005	船舶电气设施.第303部分:设备.电力和照明变压器船用電気設備―第３０３部：機器―動力及び照明用変圧器	Electrical installations in ships -- Part 303: Equipment -- Transformers for power and lighting
JIS S2142-2000	燃气设备的点火变压器燃焼機器用変圧器	Ignition transformers for burning apparatus
